Panasonic AV-HSW10 Compact Switcher

Manufacturer: Panasonic Broadcast
SKU: PAN-AVHSW10
$8,051.00 CAD
$8,051.00 CAD
Sale Sold out
Shipping calculated at checkout.

Revolutionary NEW IP Live Switcher Enhances Online Communication to New Heights

The AV-HSW10 is specifically crafted to cater to the needs of live events, be it high-flex university courses, smaller corporate events, or webinars that require seamless switching between multiple cameras and direct streaming from the switcher. Its compact, notebook-sized design is ideal for production crews operating in more intimate venues. With its user-friendly buttons, T-shaped fader, and intuitive on-screen display, it ensures a hassle-free experience. Moreover, it guarantees top-notch broadcast image quality and exceptional performance, thanks to its advanced 10bit processing. Additionally, it offers extensive connectivity options and supports various I/O's and streaming protocols, including SDI, HDMI, NDI®, SRT, and RTMP.

Key Features:

1. A wide range of interfaces to cater to various needs.

2. Multiple keyers to enhance the visual appeal of videos.

3. A multiviewer with 10 selectable patterns.

4. Software control panel for remote access.






This compact, notebook-sized device provides broadcast-quality video and supports multiple IP protocols, enabling effortless video production and distribution over IP networks



Video Input 3G-SDI
Baseband mode: 4 or 3
IP mode: 1
HDMI
Baseband mode: 1 or 2
IP mode: 1
NDI(R)*1*2/Streaming
Baseband mode: 2
IP mode: 3
Video Output 3G-SDI
Baseband mode: 2
IP mode: 2
HDMI
Baseband mode: 1
IP mode: 2
NDI(R)*1*2/Streaming
Baseband mode: 2
IP mode: 2
3G-SDI 1080/59.94p,50p,29.97p,25p,24p,23.98p
1080/59.94i,50i
720/59.94p,50p
Audio IN: RCA x 2, OUT: φ3.5 mm TRS
KEYER 2 (PinP, Linear key,
Luminance key, Chroma key)
AUX 2
Genlock BB or Tri-level (Input/through output)
USB USB-Type A x 1 (USB Memory)
Dimensions (W x H x D) 254 mm x 175 mm x 67 mm
(10 inches x 6-7/8 inches x 2-5/8 inches)
Power Consumption 45 W (TBD)
